Specifications
FEATURES
- Lightweight 6066 triple butted aluminium frame
- Full carbon tapered fork
- Less aggressive geometry than the SCULTURA CF5 and CF3 models
- Shimano 105 11-speed groupset
- MERIDA EXPERT SL handlebar and MERIDA EXPERT CC stem
- MERIDA EXPERT CC carbon seat post
SPECIFICATIONS
Brakes
Shimano 105
Hydraulic Disc
Frame
SCULTURA Disc LITE
material: aluminium 700x28C max. wheelsize 100x12/ 142x12mm axle standard Pressfit bottom bracket standard
Frame Size
3XS, XXS, XS, S, S/M, M/L, L, XL
Fork
SCULTURA CF2 Disc
700x28C max. wheelsize
Color
GOLDEN RED (GREY)
Derailleur (F)
Shimano 105
Derailleur (R)
Shimano 105
GS
Rotors
Shimano RT10
160mm
Shifter Front
Shimano 105 Disc
Shifter Rear
Shimano 105 Disc
Brake Lever
Shimano 105
Brake Front
Shimano 105
Hydraulic Disc
Brake Rear
Shimano 105
Hydraulic Disc
Chain
KMC X11
Crank
Shimano 105
50-34 teeth 165 mm-XXS, 170 mm-XS/S, 172.5 mm-SM/ML, 175 mm-L/XL
Hub Front
VP CLK170F
100x12mm width front hub 28 spoke holes Centerlock
Hub Rear
VP CLK270R
142x12mm width rear hub 28 spoke holes Centerlock
Rim
MERIDA EXPERT SL
17mm inner width 22mm height material: aluminium
Freewheel
Shimano CS-R7000
11-30 teeth 11 speed
Tyre Front
Maxxis Pursuer
700x25C fold
Tyre Rear
Maxxis Pursuer
700x25C fold
Spokes
Double Butted Black stainless
Handlebar Stem
MERIDA EXPERT CC
31.8mm diameter material: aluminium -5° stem angle 80 mm-XXS/XS, 90 mm-S, 100 mm-SM/ML, 110 mm-L/XL
Handlebar
MERIDA EXPERT SL
material: aluminium 380mm(XXS) 400mm (XS-S) 420mm (M) 440mm (L-XL)
Headset
MERIDA M2331
Seat Post
MERIDA EXPERT CC
27.2mm diameter 15mm setback Carbon
Saddle
MERIDA COMP SL
V-mount
Max. Weight
120 kg
GEOMETRY
Frame Size | 3XS | XXS | XS | S | S/M | M/L |
---|---|---|---|---|---|---|
Tyre Sizes | 28" | 28" | 28" | 28" | 28" | 28" |
ST seat tube [mm] | 410 | 440 | 470 | 500 | 520 | 540 |
TT top tube [mm] | 500 | 515 | 520 | 530 | 545 | 560 |
CS chain stay length [mm] | 408 | 408 | 408 | 408 | 408 | 408 |
HTA head tube angle [°] | 70.5 | 71 | 71 | 72 | 73 | 73 |
STA seat tube angle [°] | 75 | 75 | 74.5 | 74 | 74 | 73.5 |
BD bottom bracket drop [mm] | 70 | 66 | 66 | 66 | 66 | 66 |
HT head tube [mm] | 100 | 120 | 130 | 140 | 150 | 170 |
FL fork length [mm] | 374 | 374 | 374 | 374 | 374 | 374 |
R reach [mm] | 366 | 376 | 373 | 375 | 386 | 390 |
S stack [mm] | 498 | 519 | 529 | 542 | 555 | 574 |
WB wheel base [mm] | 978 | 982 | 983 | 979 | 985 | 995 |
SH stand over height [mm] | 668 | 697 | 720 | 744 | 762 | 779 |
Rider Height: Approx. rider height is a recommendation, and should be used as a guide only. To ensure a proper fit, we recommend calling our nearest store to discuss your optimal size.
