Specifications
Sizes
27.5: XS, S 29: S, M
Colours
Black, Pale Moss
Frame
ALUXX-Grade aluminium, disc
Fork
SR Suntour XCE 28, coil spring, QR, steel steerer XS: 80mm travel (27.5) S: 80mm travel (27.5) / 100mm travel (29) M: 100mm travel (29)
Shock
N/A
Handlebar
Giant Connect Trail, 31.8mm
Grips
Liv Sole-O
Stem
Giant Sport, 7-degree XS: 40mm (27.5) S: 40mm (27.5) / 40mm (29) M: 50mm (29)
Seatpost
Giant Sport, 30.9mm
Saddle
Liv ErgoContact Trail
Pedals
MTB caged
Shifters
microSHIFT Acolyte, 1x8
Front Derailleur
N/A
Rear Derailleur
microSHIFT Acolyte, M5185M w/clutch
Brakes
Tektro HD TKD-176, hydraulic, Tektro rotors [F]180mm, [R]160mm
Brake Levers
Tektro HD TKD-176
Cassette
microSHIFT Acolyte H083, 12x46
Chain
KMC 8.3
Crankset
ProWheel EPRO, 30t (29"), 32t (27.5") XS: 165mm (27.5) S: 165mm (27.5) / 170mm (29) M: 170mm (29)
Bottom Bracket
Cartridge
Rims
Giant GX03V 29 or 27.5, alloy, double wall, 28H
Hubs
Alloy, sealed bearing, [F] 9mm QR, [R] 12x142 thru-axle
Spokes
Stainless, 14g
Tyres
Maxxis Ikon 27.5" or 29x2.2", wire bead
Extras
2.4" max tire size, max chainring 32T
Max Tyre Clearance
2.4" max tyre size
Max Chainring Size
32t max chainring size
Weight
The most accurate way to determine any bikeΓs weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
