Specifications
Motor
SyncDrive Sport 2, 75Nm, powered by Yamaha
Controller
Giant RideControl Dash, Smart Assist automatic mode, 5 support levels, USB-C (10W)
Display
RideControl Dash, full color lcd screen
Battery
EnergyPak Smart 625, EnergyPak Plus 250 range extender compatible
Charger
Giant EnergyPak 4A smart charger compact
Connectivity
Giant RideControl App enabled ANT+ wireless display signal with e-bike profile
Sizes
M, L, XL
Colours
Misty Forest
Frame
ALUXX aluminum, Overdrive 1.8" - 1.5" head tube, integrated battery, integrated KSA40 kickstand mount
Fork
SR Suntour XCM34 LO, 100mm travel, Hydraulic Lockout, 15x110mm AH Axle
Shock
N/A
Handlebar
Giant Connect Riser
Grips
Gant Connect Ergo Max w/bar-end
Stem
Giant Contact
Seatpost
Giant 30.9mm, 2-bolt Micro Adjustable, Forged Aluminium
Saddle
Selle Royal Vivo Ergo Moderate Unisex
Pedals
Platform
Shifters
Shimano Deore, LinkGlide
Front Derailleur
N/A
Rear Derailleur
Shimano Deore LinkGlide, 10-speed, Shadow+
Brakes
Shimano BR-MT200, hydraulic disc, 180mm
Brake Levers
Shimano BL-MT200
Cassette
Shimano LinkGlide, CS-LG400-10, 11-43T, 10-speed
Chain
Shimano LinkGlide, CN-LG500
Crankset
Forged Alloy Direct spider/chainguard 46T Steel
Bottom Bracket
N/A
Rims
eX25
Hubs
Giant eTracker
Spokes
Stainless steel, e-bike optimized
Tyres
Crosscut Gravel 2, 700x57c, Wire Bead, Tubeless Ready
Extras
KSA40 direct mount kickstand
Lighting
Recon E HL50 StVZO [F]AXA NYX 6-12V E-bike tail light with brake sensor [R]
