Specifications
FRAME
Felt Gravel | SuperLite aluminium with Custom Yoke for massive tyre clearance / Custom Butted tubing / Hydroformed tubing / SuperSmooth welding tech, Threaded | T47 86.5mm, bottom bracket, Felt ControlTaper | 1.125-1.5" head tube, Internal | mechanical specific routing, with Standard | 27.2mm post, 31.8mm clamp, integrated rack mount / 6061 aluminium, Cr-Mo bolt
FORK
Felt Gravel - Adventure | UHC Advanced carbon fiber with Monocoque construction tech, Disc, Flat Mount | Ø140mm minimum. Fork offset: 40mm
FRAME PROTECTION
Clear vinyl for chain slap protection / Clear vinyl for head tube protection
HEADSET
IS (NO.42) Top Cap: Felt Tornado / Top Cover: Felt VariableHeight (20mm PC, 4.5mm aluminium) / Bearings: FSA integrated sealed cartridge / Spacers: FSA nylon (10mm, 2x5mm) / Compression Device: for carbon steerer tube / Crown Race: FSA alloy
AXLES
Front: TA 12x100 Devox AxleTA 130.5 | 125mm + 5.5mm head, M12 x 1.5P x 17mm, Switch lever compatible | Rear: TA 12x142 Devox AxleTA 172-9 L | 163mm + 9mm head, M12 x P1.0 x 19mm for Syntace X-12, with SL02 Switch hollow lever
MAX TYRE CLEARANCE
700c: 45mm (6mm) / 650b: 2.1" (6mm)
SHIFTING
1x11-speed, SRAM Force 1 Hydraulic
FRONT DERAILLEUR
-
REAR DERAILLEUR
SRAM Force 1, long cage
CRANK
Praxis Works Zayante Carbon-S, 40T DM WT, 47cm: 165mm / 51cm: 170mm / 54, 56cm: 172.5mm / 58, 61cm: 175mm
BOTTOM BRACKET
Praxis Works M30 T47 86.5mm
CASSETTE
SRAM PG-1130, 11-42T
CHAIN
SRAM PC-1130
BRAKE LEVERS
-
BRAKE CALIPERS
SRAM Force 1, hydraulic disc, flat mount
BRAKE ROTORS
SRAM Centerline, Center Lock, 160mm
WHEELS
Devox WheelRDS.A0 GXA | 30/21, Aluminium. Tubeless Compatible. J-Bend, 2.0, stainless steel, black spokes.
HUBS
Front: Devox HubRDF.1 | J-Bend, Center Lock, 24h, TA 12x100, sealed cartridge bearings | Rear: Devox HubRDR.1 | J-Bend, Center Lock, 24h, TA 12x142, 11-speed, sealed cartridge bearings
TYRES
Vittoria Terreno Dry, Tubeless Ready (TNT), Anthracite Sidewall, 700x40c
HANDLEBAR
Devox DBar.A1 GXA, 31.8mm ø, 126mm, 16° flare drop, 70mm reach, 47cm: 40cm / 51cm: 42cm / 54cm: 44cm / 56, 58, 61cm: 46cm width
TAPE
Felt VelvetGel tape with 3M reflective base and Felt Bubble-Tech F-Wing bar end plugs
STEM
Devox StemR.A1, 31.8mm DIAM, -7°, 47cm: 80mm / 51cm: 90mm / 54, 56cm: 100mm / 58cm: 110mm / 61cm: 120mm, -
SEATPOST
Devox Post.C2, 18mm offset, 47, 51cm: 300mm / 54, 56, 58, 61cm: 350mm
SADDLE
Prologo Dimension NDR T4.0
INCLUDED EXTRAS
BREED fender system - removable eye-bolts, chain stay fender mount, and seat stay fender bridge / Carbon assembly paste
