Specifications
Motor
SyncDrive Sport 2, 75Nm, powered by Yamaha
Controller
Giant RideControl App enabled ANT+ wireless display signal with e-bike profile
Display
RideControl Dash, full colour LCD screen
Battery
Giant EnergyPak 625Wh, Aluminium casing with highest safety standard (EN50604), CO2 Neutral production, Giant EnergyPak Plus 250 range extender compatible
Charger
Giant EnergyPak 4A smart charger compact, 60% charge in 2:30h
Sizes
S, M, L, XL
Colours
Black Diamond
Frame
ALUXX SL-grade aluminium, 125mm travel FlexPoint suspension system, 148x12 rear axle, Universal Derrailleur hanger, 184x44 shock, 1.5~1.8" headset
Fork
SR Suntour XCR 34 LO-R, 140mm travel, tapered steerer, Lockout, 110x15 thru-axle
Shock
SR Suntour Raidon R, 190x45mm, recommended sag: 30%
Handlebar
Giant Connect TR Riser
Grips
Giant Tactal single lock-on
Stem
Giant Contact
Seatpost
Giant 30.9mm, 2-bolt Micro Adjustable, Forged Aluminium
Saddle
Giant Sport
Pedals
Platform
Shifters
Shimano Deore LinkGlide
Front Derailleur
MRP HD2 co-moulded chain guide
Rear Derailleur
Shimano Deore LinkGlide, 10-speed
Brakes
Tektro HD-M745 Orion, 4-piston, hydraulic disc, 203mm
Brake Levers
Tektro HD-M745 Orion
Cassette
Shimano LinkGlide, CS-LG400-10, 11-43T, 10-speed
Chain
Shimano, LinkGlide, CN-LG500
Crankset
FSA Comet E-Bike crank arm set FSA MegaTooth Direct-mount 1X steel 36T
Bottom Bracket
N/A
Rims
Giant AM 29"
Hubs
Giant eTracker Boost, [F] 110x15 [R] 148x12mm
Spokes
Stainless Steel
Tyres
Maxxis Minion DHF 29X2.50" Foldable, TLR, EXO, 60TPI [F]Maxxis Dissector 29X2.40" WT Foldable, TLR, EXO, 60TPI [R]
Extras
-
Lighting
-
Lock
Torx 25 Battery Lock with built-in Torque limiter
